Uzvi Software Bilgisayar Ltd.Şti.

Touch POS Libra

-Bütünleşik Screen -touchscreen; 5 Wire Resistive Touch Resistive -High Quality Box; Aluminum Casting & Plastic can -Selected different CPU Classes (baytrail J1900, Core-i3 / i5 / i7) -Fansız Cooling (ventilation None) Multiple Connection Options 4 x USB 2.0, 2 x USB 3.0, 1 x Ethernet, 2 x RS232 - externally accessible 2.5 "HDD or SSD Drive Docking -Provide connected 10.1 '' screen; VFD Support -Ves Mounting Slots -2-Year Warranty

MODEL	J1900	İ5
Processor	Baytrail J1900 Intel 2.0 GHz (Quad-Core)	2.30 GHz Intel Core I5 6200 (Quad Core)
chipset	Intel baytrail - D	Intel Nm70 Express
Memory (RAM)	DDR3 SODIMM 4GB to 8GB (1333/1666 MHz)	DDR3 SODIMM 4GB to 8GB (1333/1666 MHz)
Image Memory	Intel HD Graphics Core E3800	Intel HD Graphics 520
Flash Disk	SSD 120 GB HDD 2.5 '' / mSATA	SSD 120 GB HDD 2.5 '' / mSATA
HDD	HDD 1 x 2.5 ''	HDD 1 x 2.5 ''
Touch Panel	10.1 "LED-LCD Resistive panels projected	10.1 "LED-LCD Resistive panels projected
Resolution	1366 x 768	1366 x 768

INPUTS / OUTPUT
VGA	one	one
Power Button	one	one
USB	4 x USB 2.0 + 2 x USB 3.0	6 x USB 3.0
Serial / COM	2 x RS-232	2 x RS-232
LAN	1 LAN 10/100/1000	1 LAN 10/100/1000
Cash Drawer	1 x RJ 11 (12V / 24V) Optional	1 x RJ 11 (12V / 24V) Optional
Display Port	1 (2.DISPLAY)	1 (2.DISPLAY)
HDMI	one	one

DRIVERS
Customer Display	Graphic Customer Display
Mini PCI Port	Integrated
Power source	Adapter 12V / 4-7A
Dimensions (H x W x D)	260 x 700 x 380mm (Working Position 45 °)
Net weight	10.5 kg (or customer display Power Supply Not Included)
Material	High Quality Box, Aluminum Casting & Plastic
Color	Module 1 color (Black)
compatible OS	Windows 7, Windows 8.1, Windows 10, Posready 7

OPTIONAL ACCESSORIES
Graphical customer display (higher readability)
Card reader
10.1 '' rear screen support (high çöznürlük)
